Grade 5 Ti-6Al-4V Titanium Sheet & Plate
Alpha-beta alloy with exceptional tensile strength, lightweight performance, and fatigue resistance for aerospace, defense, and high-spec industrial applications.
ASTM B265 Titanium Plate & Sheet Manufacturer
Almerca Titanium Industry Co., Ltd. is an ISO 9001:2015 certified manufacturer and premier global supplier of high-performance Titanium Plates and Sheets. We specialize in producing ASTM B265, ASME SB265, and AMS 4911 compliant Grade 1, Grade 2, Grade 5 (Ti-6Al-4V), Grade 7 (Ti-Pd), Grade 9, and Grade 12 titanium plates. Engineered for superior corrosion resistance, extreme strength-to-weight ratio, and long operational service life in critical aerospace, chemical processing, marine, oil & gas, and medical engineering applications.
ASTM B265 / ASME SB265 Certified
EN 10204 3.1 Mill Test Certificate
100% Ultrasonic & PMI Inspected
Precision Waterjet & CNC Cut-to-Size
Hot-Selling Titanium Plate Products
Grade 2 Commercially Pure Titanium Plate
The industrial benchmark for chemical processing and seawater applications. Offers excellent weldability, ductility, and high corrosion resistance.
Grade 7 Titanium Palladium Alloy Plate
Enhanced with 0.12%–0.25% Palladium for maximum corrosion resistance in severe reducing acid environments and chemical reactors.
Grade 12 Titanium Alloy Plate
Alloyed with Molybdenum and Nickel to provide higher elevated-temperature strength and crevice corrosion resistance in hot brine solutions.
Titanium Plate Technical Specifications & Manufacturing Standards
Almerca Titanium Industry Co., Ltd. manufactures titanium plates with thicknesses ranging from 0.5 mm up to 100 mm, widths up to 3000 mm, and custom lengths based on your technical drawings.
| Parameter | Manufacturing Capability & Standard Range |
|---|---|
| Standard Compliance | ASTM B265, ASME SB265, AMS 4911, AMS 4902, ASTM F67, ASTM F136, MIL-T-9046 |
| Titanium Grades | Commercially Pure: Grade 1, Grade 2, Grade 3, Grade 4 Titanium Alloys: Grade 5 (Ti-6Al-4V), Grade 7 (Ti-Pd), Grade 9 (Ti-3Al-2.5V), Grade 12 (Ti-0.3Mo-0.8Ni), Grade 23 (Ti-6Al-4V ELI) |
| Thickness Range | 0.5 mm – 100 mm (0.02" – 4.0") | Custom gauge plates available |
| Width Range | Up to 3000 mm (118") max width |
| Length Range | Up to 6000 mm (236") max length |
| Surface Finish Options | Acid Pickled, Cold Rolled Bright, Sandblasted, Polished (Mirror Finish), Machined surface |
| Processing Technology | Hot Rolling, Cold Rolling, Vacuum Heat Treatment, Precision CNC Shearing, Waterjet Cutting |
| Quality Certificates | ISO 9001:2015, EN 10204 3.1 MTC, TÜV, PED 2014/68/EU, SGS, Third-party lab reports |
Mechanical Properties Comparison
Our titanium plates undergo rigorous mechanical testing to ensure strict conformity with international ASTM/ASME standards for structural integrity.
| Titanium Grade | Density (g/cm³) | Tensile Strength Rm (MPa) | Yield Strength Rp0.2 (MPa) | Elongation A5 (%) |
|---|---|---|---|---|
| Grade 1 (CP Ti) | 4.51 | ≥ 240 | 170 – 310 | ≥ 24 |
| Grade 2 (CP Ti) | 4.51 | ≥ 345 | 275 – 450 | ≥ 20 |
| Grade 5 (Ti-6Al-4V) | 4.43 | ≥ 895 | ≥ 828 | ≥ 10 |
| Grade 7 (Ti-Pd) | 4.51 | ≥ 345 | 275 – 450 | ≥ 20 |
| Grade 12 (Ti-Mo-Ni) | 4.51 | ≥ 485 | ≥ 345 | ≥ 18 |
Key Titanium Plate Grades & Industry Selection Guide
Grade 2 Titanium Plate (UNS R50400)
Industrial Workhorse
Commercially Pure Grade 2 is the most widely utilized titanium plate grade across global process industries. It provides an outstanding balance of moderate strength, exceptional ductility, and superior resistance to oxidizing media, seawater, and organic acids. Ideal for heat exchangers, reaction vessels, desalination plants, and chlor-alkali systems.
Grade 5 Ti-6Al-4V Titanium Alloy Plate (UNS R56400)
High Strength & Aerospace Grade
Grade 5 is an alpha-beta titanium alloy containing 6% Aluminum and 4% Vanadium. It delivers double the yield strength of Grade 2 pure titanium while maintaining light weight and impressive fatigue limits. Extensively specified in aerospace structural frames, jet turbine components, offshore oil tools, and high-performance racing parts.
Grade 7 Titanium Palladium Alloy Plate (UNS R52400)
Severe Acid Resistance
Grade 7 is physical and mechanical twin to Grade 2, but augmented with 0.12% to 0.25% Palladium. This addition dramatically increases corrosion resistance in dilute hydrochloric and sulfuric acids under high temperatures and crevice conditions.
Grade 23 Ti-6Al-4V ELI Titanium Plate (UNS R56401)
Medical & Cryogenic Grade
Grade 23 is an Extra Low Interstitial (ELI) version of Grade 5. Reduced interstitial elements (oxygen, nitrogen, iron) yield superior fracture toughness and ductility at cryogenic temperatures, making it the preferred alloy for medical implants and aerospace cryogenic tanks.
Manufacturing Process & Quality Control Assurance
Almerca Titanium Industry Co., Ltd. enforces end-to-end quality supervision from raw sponge titanium melting to final dimensional packaging. Our state-of-the-art manufacturing guarantees zero internal defects and uniform grain structure.
1
VAR Sponge Melting
2
Forging & Slab Blooming
3
Hot & Cold Rolling
4
Vacuum Annealing
5
Pickling / Polishing
6
UT & PMI Testing
Rigorous Inspection Protocols
Every titanium plate order is verified through thorough inspection procedures:
- Chemical Composition Verification: Spectrometric analysis for compliance with ASTM B265 limits.
- Mechanical Property Testing: Room temperature tensile, yield, elongation, and bend testing.
- Ultrasonic Inspection (UT): Performed according to AMS 2631 / ASTM A578 to detect micro-porosity, cracks, and internal inclusions.
- Dimensional & Surface Inspection: Laser checking of flat tolerance, diagonal squareness, thickness uniformity, and surface finish.
Global Application Areas
Chemical & Petrochemical
Used for shell-and-tube heat exchangers, PTA plants, reaction vessels, chlor-alkali electrolysis cells, and acid piping systems.
Aerospace & Defense
Structural airframe panels, turbine engine nacelles, heat shields, missile casings, and high-stress fastener blank plates.
Marine & Offshore Engineering
Desalination evaporators, submarine pressure hulls, offshore platform cooling loops, and subsea riser components resistant to marine biofouling.
Frequently Asked Questions (FAQ)
What is the difference between Titanium Sheet and Titanium Plate?
By standard industry definition, titanium sheets are under 6.0 mm (0.236 inches) in thickness, usually produced via cold rolling to deliver a bright surface and tight tolerance. Titanium plates are 6.0 mm and thicker, produced by hot rolling for heavy-duty structural, chemical vessel, and mechanical machining applications.
What standard mill test documentation is provided?
We provide an official EN 10204 3.1 Mill Test Certificate with every shipment. The MTC includes chemical composition, heat number, mechanical test values (tensile strength, yield strength, elongation), heat treatment conditions, non-destructive testing (NDT/UT) results, and dimensional check records.
Can Almerca Titanium provide cut-to-size plates based on custom drawings?
Yes. We offer in-house CNC precision processing including waterjet cutting, laser shearing, beveling, surface grinding, and hole drilling. Send us your CAD drawings (DXF, DWG, PDF) for an accurate quote.
What is the typical lead time for titanium plate orders?
Standard stock items (Grade 2 and Grade 5 plates in common standard dimensions) can ship within 3–7 business days. Custom thickness, special alloy grades, or cut-to-size items usually take 10–20 days depending on quantity and specification requirements.
